Product Description

The DS3820AIQA1A1A is a part of General Electric’s Mark IV Speedtronic line. The DS3820AIQA1A1A has eight large black rectangles. The DS3820AIQA1A1A has four metal platforms in between the black rectangles. Three of the metal platforms has twelve metal screws on the top. The fourth metal platform has seventeen metal screws on the top. The DS3820AIQA1A1A can be installed using the two thin metal edges with two screw ports on either side. The DS3820AIQA1A1A has eleven small black half circles. These half circles are called transistors. A transistor is a semi-conductive device that helps to amplify or alter electrical power or electronic signals. The didoes direct energy by only allowing it to flow in one direction. The DS3820AIQA1A1A has thirty-two large bright red diodes, sixteen large bright yellow diodes, and sixty-five small teal blue diodes.  The DS3820AIQA1A1A has four small blue male connection terminals with ten metal pins in each terminal. The DS3820AIQA1A1A has six blue male connection terminals with twenty-six metal pins inside the terminal. These male connection terminals connect the DS3820AIQA1A1A with other circuit boards surrounding it. Resistors have multiple rings of several colors. The resistors can have up to five rings to help indicate how much energy it can restrict. The DS3820AIQA1A1A has sixty-five tiny light-colored resistors and sixteen large black resistors.



For a price quote or additional information please call AX Control.



** AX Control suggests referring to the original manufacturer's manual for all safety and installation methods. Technical support for the DS3820AIQA1A1A was initially provided by General Electric.

Repair Services For DS3820AIQA1A1A

Type Lead Time Price Action
Repair Service 1-2 weeks $419

Our highly skilled technicians can repair your DS3820AIQA1A1A. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
