DS3820AIQA

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
GE CIRCUIT BOARD MARK IV

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS3820AIQA to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3820AIQA
  • SKU: DS3820AIQAGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

About the DS3820AIQA

The DS3820AIQA is a part of General Electric’s Speedtronic Mark IV line. The DS3820AIQA has thirty-two large bright red diodes, sixteen large bright yellow diodes, and sixty-five small teal blue diodes. The didoes direct energy by only allowing it to flow in one direction. The DS3820AIQA has sixty-five tiny light-colored resistors and sixteen large black resistors. Resistors have multiple rings of various colors rings. The resistors can have up to five rings to help indicate how much energy it can restrict. The DS3820AIQA has eleven small black half circles. These half circles are called transistors. A transistor is a semi-conductive device that helps to amplify or alter electrical power or electronic signals. The DS3820AIQA has four small blue male connection terminals with ten metal pins in each terminal. The DS3820AIQA has six blue male connection terminals with twenty-six metal pins inside the terminal. These male connection terminals connect the DS3820AIQA with other circuit boards surrounding it. The DS3820AIQA has eight large black rectangles. The DS3820AIQA has four metal platforms in between the black rectangles. Three of the metal platforms has twelve metal screws on the top. The fourth metal platform has seventeen metal screws on the top. The DS3820AIQA can be installed using the two thin metal edges with two screw ports on either side.

For a price quote or additional information please call AX Control.

** AX Control suggests referring to the original manufacturer's manual for all safety and installation methods. Technical support for the DS3820AIQA was initially provided by General Electric.

Repair Services For DS3820AIQA

Type Lead Time Price Action
Repair Service 1-2 weeks $454

Our highly skilled technicians can repair your DS3820AIQA. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
