This DS3800XTFT Turbine Control Board was manufactured for General Electric's Mark IV Turbine Control System Series.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS3800XTFT to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800XTFT
  • SKU: GBTC-12901
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

DS3800XTFT Technical Specifications

Manufacturer General Electric
Series Mark IV Speedtronic
Functional Part Number DS3800XTFT
Functional Acronym XTBA
Revision Quantity 0 Revisions
Shipping Weight 1 lb

About the DS3800XTFT

  • The DS3800XTFT is a printed circuit board used within the Mark IV Speedtronic system.
  • This 3800-series board is designed to work with other components in its series.
  • The Mark IV Speedtronic system was the first industrial turbine control system from GE to offer triple modular redundant control.
  • Includes an operator interface for communication with the turbine system, panel-mounted with membrane switches for inputs.
  • Considered an obsolete legacy GE Mark product series due to discontinued original manufacture.

Hardware Tips and Specifications
  • Form Factor: Small and long rectangular board with few mounted components.
  • Alignment: Marked on two sides for alignment purposes.
  • Mounting: Drilled in several places along its edges, likely for installation.
    • Note: Not supplied with a standard Mark IV Series VME Rack installation-minded metal faceplate.
  • Identification: Codes along the board edges identify the board and provide information regarding location and proper wiring connections.
  • Components: Limited to:
    • A single vertical pin connector.
    • Two jumper switches.
    • Eight plug connectors (in two lines of four, equidistant).
  • Fragility: Outside edges are considered relatively fragile due to being component-bare compared to similar Mark IV Series products.

Documentation and Product Information
  • Installation & Maintenance: Use original documentation from General Electric (arrived with OEM purchase).
  • Documentation Replacement: AX Control can typically assist with replacements if original documents are lost.
  • Shipping: In-stock products ship quickly (contact sales representative for specific shipping times).
  • Product Number Information: The DS3800XTFT functional product number does not display details such as:
    • Mark IV Series assembly style.
    • PCB coating style.
    • Mark IV Series product grouping.

Frequently Asked Questions about DS3800XTFT

Where specifically was this DS3800XTFT device manufactured?

This DS3800XTFT PCB was originally manufactured in GE's Salem, Virginia factory plant location.

Would this DS3800XTFT device be protected by any warranty here after my purchase?

Yes. This DS3800XTFT device would be protected by a guaranteed three-year PCB warranty following an original purchase here.

Reviews For DS3800XTFT

Internal Review
(4.0)

This DS3800XTFT Mark IV Turbine Control System Series product offering's greater Mark IV Series is rather self-explanatory; possessing various turbine-based applications. Not much is known about the DS3800XTFT product itself, given its characteristic lack of originally-pertinent instructional manual materials online. With this being the case, its Mark IV Series is well-documented as one of the lastly-developed GE Mark Series to make use of the signature Speedtronic control system technology, which was first seen with the release of the previous Mark I Series in the mid to later 1960s. This DS3800XTFT PCB is available for both repair or replacement today here right now. - AX Control Lead Technician
