Product Description

The DS3800XTES1A1A from GE is a replacement part for the company’s Mark IV turbine control system line.  Although earlier turbine control systems like the MKI and MKII were appreciated for their reliability and longevity, it was the Mark IV that offered significant and real improvements to turbine performance through its unique control design system.  This triple modular redundancy system significantly improved the reliability and uptime of connected turbine systems.

The DS3800XTES1A1A board component is a narrow and long board.  It has only a few components mounted to its surface.  The most prominent of these is a large black connector mounted to its rear edge.  Other components include three LEDs (all amber) lined up toward the center of the board.  Additionally, the board includes several vertical plug connectors, resistors, diodes, and capacitors.  These components are marked with reference designators to help users identify each component.

The DS3800XTES1A1A is marked on the board’s surface with the General Electric logo. It also carries the board ID, wiring codes, and version codes. These codes will help you as you install and connect the board. Please refer to original documentation, including manuals, GE datasheets, and product guides for additional information regarding safe handling and proper installation procedures.  If you no longer have these documents, we may be able to help with replacements.

AX Control ships components around the world every day.  We will make sure your part will arrive in the same condition it left our facility.  If you are local to our North Carolina warehouse, we are also happy to work with your courier for a faster turnaround.


Repair Services For DS3800XTES1A1A

Type Lead Time Price Action
Repair Service 1-2 weeks $392

Our highly skilled technicians can repair your DS3800XTES1A1A. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
