Product Description

The DS3800NVAA1D1A is a circuit board for the Speedtronic Mark IV line created by GE. The DS3800NVAA1D1A has around one-hundred and sixty-five resistors (have color bands on the outside). The DS3800NVAA1D1A has twenty-two integrated circuits. The integrated circuits are split into two groups known as EPROMs and EEPROMs. The EEPROM is a pre-programmed integrated circuit that cannot be altered. The EPROM is a pre-programmed integrated circuit that can be updated. There is a “SPARE” section to add an additional EPROM or EEPROM if additional data is required. The DS3800NVAA1D1A has four tiny black transformers which alter and changes electronic signals and electrical power. The DS3800NVAA1D1A has thirty-five dark blue diodes, sixty-eight clear diodes with orange tips, twenty-eight large light blue diodes, and eight tiny light blue diodes, and one teal blue diode. These allow energy to flow in one direction. The DS3800NVAA1D1A has three vibrant yellow capacitors, nine dark red capacitors, four grey capacitors, one large vibrant orange capacitor, and two pale yellow capacitors. The DS3800NVAA1D1A has one yellow colored LED. The DS3800NVAA1D1A has a large black battery pack. The DS3800NVAA1D1A has seven blue variable resistors also referred to as Potentiometers. The variable resistors are adjustable components that can change the amount of energy through the circuit board. The DS3800NVAA1D1A has one glass fuse. The DS3800NVAA1D1A has one large feminine terminal port to connect to other circuit boards. The DS3800NVAA1D1A has a few holes to put anchors to attach the DS3800NVAA1D1A circuit board in place, along with two clasps.

Call AX Control today if you’d like additional information about the product or would like a quote.

Repair Services For DS3800NVAA1D1A

Type Lead Time Price Action
Repair Service 1-2 weeks $447

Our highly skilled technicians can repair your DS3800NVAA1D1A. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
