DS3800NVAA

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
VOLTAGE DE CURRENT MARK IV GE

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS3800NVAA to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800NVAA
  • SKU: DS3800NVAAGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

About the DS3800NVAA

The DS3800NVAA is a circuit board for the Mark IV Speedtronic line created by General Electric. The DS3800NVAA has a large black battery pack. The DS3800NVAA has one glass fuse. The DS3800NVAA has seven blue variable resistors also referred to as Potentiometers. The variable resistors are adjustable components that can change the amount of energy through the circuit board. The DS3800NVAA has one large female terminal port to connect to other circuit boards. The DS3800NVAA has a few holes to put anchors to attach the DS3800NVAA circuit board in place, along with to clasps. The DS3800NVAA has three bright yellow capacitors, nine deep red capacitors, four silver capacitors, one large bright orange capacitor, and two light yellow capacitors. The DS3800NVAA has one amber colored LED. The DS3800NVAA has around one-hundred and sixty-five resistors. The DS3800NVAA has twenty-two integrated circuits. The integrated circuits are split into two groups known as EEPROMs and EPROMs. The EEPROM is a pre-programmed integrated circuit that cannot be altered. The EPROM is also a pre-programmed integrated circuit that can be updated. There is a “SPARE” section to add an additional EEPROM or EPROM if additional data is required. The DS3800NVAA has four small black transformers which alter and changes electronic signals and electrical power. The DS3800NVAA has thirty-five dark blue diodes, sixty-eight clear diodes with orange tips, twenty-eight large pale blue diodes, and eight small light blue diodes, and one teal blue diode. These allow energy to flow in one direction.

Call AX Control today if you’d like additional information about the product or would like a quote.

Repair Services For DS3800NVAA

Type Lead Time Price Action
Repair Service 1-2 weeks $410

Our highly skilled technicians can repair your DS3800NVAA. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
