The DS3800NTEA1A1A is a printed circuit board from GE

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a DS3800NTEA1A1A to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

DS3800NTEA1A1A

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
The DS3800NTEA1A1A is a printed circuit board from GE

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a DS3800NTEA1A1A to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Product Description

The DS3800NTEA1A1A is a termination board manufactured by General Electric for their Mark IV series.   Designed for gas or steam turbine management, the MKIV is GE’s dedicated control system created to handle with efficiency most of the standard working procedures of turbine management, including temperature control, control sequencing, speed control, startup control, power supply, and shutdown.   It has a better-designed operator interface than the previously used MKI or MKII, and improved reliability, including a substantial decrease in GT outage rate.

The DS3800NTEA1A1A is built with a single circuit, which is a 3-state octal buffer line driver line receiver.  This buffer/driver features 400 mV of hysteresis at each low current PNP data line input, which provides improved noise rejection and high fanout outputs.

The DS3800NTEA1A1A has the code 6BA00 imprinted on one edge.  It is alignment marked and numbered behind the one mating connector on the board.  This is a 218A4553-1 connector. The board has been populated with two extractor/inserter clips, which are affixed by roller pin to each right corner.  Extractor clips can be used as either a pivot point or as a handle as needed by the technician.

The DS3800NTEA1A1A  has two rows of spare plated-through holes.  PTH allow board components to make contact with the inner conductive layer of the board.  The board is built with both metal film and carbon composite resistors. Capacitors may be fixed vacuum or other material.

Technical support for the DS3800NTEA1A1A was furnished by GE.  This includes all publications like manuals and data sheets.

Repair Services For DS3800NTEA1A1A

Type Lead Time Price Action
Repair Service 1-2 weeks $454

Our highly skilled technicians can repair your DS3800NTEA1A1A. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
