Product Description

General Electric created the DS3800NPSR printed circuit board (PCB). This product is a component in the Speedtronic Mark IV system. Mark IV is a series used for the control and automation of turbines.

The DS3800NPSR prominently features two (2) black square-shaped semiconductors. Each semiconductor has a contains a white label. On these labels is the part number F28S05/1000Z in black lettering. Positioned directly above the semiconductors are two (2) medium-sized blue capacitors. These capacitors are labeled with the designator C, as C12 and C2. Two (2) small yellow capacitors labeled C13 and C3 are located below the semiconductors. Below these capacitors are two (2) larger yellow capacitors. A long black connector port runs along the bottom of the DS3800NPSR. This port is labeled with the numbers 10 to 80 by tens. Above the two blue capacitors, there are two small yellow capacitors labeled C14 and C4. There are many other small components on the top half of the DS3800NPSR. Thirteen (13) small yellow capacitors sit on the top half of the DS3800NPSR. These capacitors are alternated with fifteen (15) small resistors banded in various colors. The capacitors and resistors are arranged in three (3) vertical columns. Two (2) integrated circuits can also be found on the top half of the DS3800NPSR. One (1) small black transistor which is shaped like a half-moon is positioned near each integrated circuit. These two transistors are labeled with the letter Q. One (1) orange light-emitting diode, or LED, is positioned near the top edge of the DS3800NPSR. Four (4) test points are also lined up along the upper edge of the DS3800NPSR near the LED.
