Product Description

The DS3800NPSM1F1D was produced by General Electric. This device is a power supply circuit board. The DS3800NPSM1F1D is part of the Speedtronic Mark IV series. This product is a printed circuit board.

The DS3800NPSM1F1D has three inductors, which are also known as coils. The inductors are labeled with the letter L, from L1 through L3. Two inductors are positioned close to the top of the DS3800NPSM1F1D. The last inductor is positioned under the other two. This inductor has a black cover on the top. The inductor is connected to the circuit board with wires. There are two large diodes on the left end of the DS3800NPSM1F1D. Each of the diodes is connected to the DS3800NPSM1F1D by two wires. Sitting in the lower left corner of the DS3800NPSM1F1D are two large silver transistors. There are four small transistors on the DS3800NPSM1F1D. Every transistor is labeled with the initial Q. A large capacitor which is blue in color is centered near the top of the DS3800NPSM1F1D. The capacitor is sitting vertically on the DS3800NPSM1F1D. Five (5) orange capacitors are located on the DS3800NPSM1F1D. Several small capacitors are seen on the surface of the DS3800NPSM1F1D. The small capacitors are in various colors like red, blue, and yellow. Every capacitor is marked with the letter C. Located on the left side of the DS3800NPSM1F1D is a fuse labeled FU1. There are also two test points placed by the upper right corner of the DS3800NPSM1F1D. Next to the fuse there are two (2) LEDs. One of the LEDs is orange and other is red.
