Product Description

The DS3800NOAA1F1D is a PCB manufactured by GE for their Mark IV series.  This series was developed for gas/steam turbine management and has improved efficiency due to some processes being automated (startup/cool down/shut down.)  The Mark IV can also be used to monitor air, fuel and water emissions.

The DS3800NOAA1F1D has one extractor clip located in each right corner of the board.  Extractors aid in insertion and extraction of PCBs, especially from tight locations; the clips give technicians a lever point or a handle to grab on to rather than hold on to the board itself.   The upper edge of the DS3800NOAA1F1D is marked for alignment, and each corner has been factory-drilled.

The DS3800NOAA1F1D acts as the motherboard to the smaller auxiliary DS3800DOAA.  This optional auxiliary board adds the capacity of multiple potentiometers and quick-connect screw mounts to the DS3800NOAA1F1D.  It is connected to the DS3800NOAA1F1D and held in place by twenty-nine board-to-board connector pins.

The DS3800NOAA1F1D has one PCB mating connector located along its left edge.  This connector is marked 218A4553-AMP 102041.

The DS3800NOAA1F1D is built with one LED (amber,) thirteen test points, a single transistor, and various resistors, capacitors, and diodes.  It has six integrated circuits, including low power, low offset voltage quad comparators, and dual operational amplifiers.

All technical support for the DS3800NOAA1F1D, including publications like datasheets and manuals, came from GE. These publications can be excellent resources for the end user for installation, repair and maintenance information.
