Product Description

The DS3800NMEC1F1D is a PCB manufactured by GE for the Mark IV system.  This system was created to manage gas and steam turbines. It is built on a microprocessor-based design with triple-redundancy backups on all protection parameters and critical controls; this allows workload to shift if ever a single PCB has an electrical issue and minimizes downtime to the entire system.  The Mark IV also allows the user to automate some standard processes, like start-up and shut down.

The DS3800NMEC1F1D is designed to act as a motor exciter control board.  It has six communication connectors for communicating with other PCBs, including two male vertical pin connectors located near its center; these are labeled DA and DB.  The board has three right-angled connectors on its right edge (218A4637P2,) along with one right-angled six-pin header.

The DS3800NMEC1F1D is built with ten transistors and seventeen test points.  It has one potentiometer and two jumper switches. Both jumpers have two settings only, the first giving the option of IN or OUT, the second the option of J32 or J33.  Jumpers allow the user to finish off circuits as they desire to customize the use of the board.

The DS3800NMEC1F1D is built with 37 circuits, including operational amplifiers, 2-input NAND buffers, voltage comparators, and oscillators.

Technical support for the DS3800NMEC1F1D, including datasheets and manuals, was provided by GE.

The OEM no longer supports Mark IV products, but AX Control will help keep your Speedtronic systems working.  Ask about our service and exchange programs.

Repair Services For DS3800NMEC1F1D

Type Lead Time Price Action
Repair Service 1-2 weeks $343

Our highly skilled technicians can repair your DS3800NMEC1F1D. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
