The DS3800NHVE1C1B is a printed circuit board from GE

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

3 Year Warranty: Learn More
Sell Surplus: Have a DS3800NHVE1C1B to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800NHVE1C1B
  • SKU: DS3800NHVE1C1BGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

DS3800NHVE1C1B

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
The DS3800NHVE1C1B is a printed circuit board from GE

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

3 Year Warranty: Learn More
Sell Surplus: Have a DS3800NHVE1C1B to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800NHVE1C1B
  • SKU: DS3800NHVE1C1BGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

Product Description

GE developed the DS3800NHVE1C1B as a Hi HP board for their Mark IV series. This series, which was developed for gas/steam turbine control, uses a variety of features to make system management more efficient, including automating some procedures like startup and shutdown. It also can monitor air, water, and fuel emissions.

The DS3800NHVE1C1B has some vertical height to it due to the attachment of six Bicron transformers (218A4886 Pl.) These transformers are placed in two rows of three and take up a large percentage of the left side of the board. Between the lines of transformers are six polyester film 2.0+/- 10% 100V capacitors, six light emitting diodes (LEDs,) and twelve carbon composite resistors banded in yellow, purple, black and gold.

The DS3800NHVE1C1B is also built with six contact points, two male communication connectors (218A4807 P4) five jumpers that can be set to H or B, and multiple straight-pin headers. The headers include six 8-position 3-pin headers, labeled p1,p2, p3 (top edge) n1, n2, and n3 (bottom edge,) and five 4-position 2-pin headers labeled 01, 02, 03, p and n, located on the right edge.

The DS3800NHVE1C1B is alignment marked and factory drilled in all corners. One drilling has been made in the center of the board. All components are labeled.

Important information for the DS3800NHVE1C1B like maintenance schedules and installation guidelines may be found within manuals and datasheets originally published by GE. GE provided all technical support for this product, including the distribution of technical publications.

Repair Services For DS3800NHVE1C1B

Type Lead Time Price Action
Repair Service 1-2 weeks $457

Our highly skilled technicians can repair your DS3800NHVE1C1B. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
