Product Description

The DS3800NHVE1A1A is a high volt board component from GE for the Mark IV series. This series was created for steam and gas turbine management. It can be used for such things as monitoring of fuel and air emissions, or to automate procedures like startup and shutdown. The Mark IV is built upon integrated chipsets that work together to cover all necessary controls and parameters even when one PCB experiences an electronics issue, thus minimizing downtime due to electronics failure.

The DS3800NHVE1A1A is factory drilled twice in each corner. It is alignment-marked on two edges and marked with the codes 6BA01 and 6DA01.

Connectors populate all edges of this board. Two vertical-pin (male) connectors are placed on the left edge. The remaining edges have header connectors attached as follows: on the top, three 3-pin eight position headers (P1/P2/P3,) on the right, five 2-pin four position headers (01/02/03/P/N,) and on the lower edge, three 3-pin eight position headers (N1/N2/N3.)

The DS3800NHVE1A1A is built with six light emitting diodes (LEDs,) five jumpers that can be set either to 'H' or 'B,' six contact points (five to the right side of the board and one in the left bottom corner,) and six transformers.

The DS3800NHVE1A1A has many capacitors, including (6) 100V 708A1 2.0 +/- 10% capacitors. Resistors may be both carbon composite or ceramic metal film.

GE provided all technical support for the DS3800NHVE1A1A including publications like manuals.
