The DS3800NGRC1H1F is a printed circuit board by GE

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a DS3800NGRC1H1F to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

DS3800NGRC1H1F

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
The DS3800NGRC1H1F is a printed circuit board by GE

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a DS3800NGRC1H1F to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Product Description

GE manufactured the DS3800NGRC1H1F as a regulator board for their Mark IV series. This series was designed for steam/gas turbine management and can automate some procedures such as startup and shutdown. It can also protect the system from operating under unsafe or adverse operating conditions.

The DS3800NGRC1H1F has the following components and specs:

  • -factory drilled in each corner for mounting.

  • -alignment markings on the top edge (A through J.)

  • -one 6-pin header.

  • -four communication ports from the 218A4637 series. This includes two P4 connectors, one P6-8927, and one P6-8920.

  • -many capacitors, usually with axial leads. These capacitors are usually polyester film and are of differing values.

  • -built with both ceramic covered metal film and carbon composite resistors.

  • -many different kinds of circuits. This includes voltage comparators (LM311J) designed with low input currents. The voltage comparators operate from a single 5V supply. The board also has super gain operational amplifiers (LM308A) which are useful for applications where high accuracy and low drift performance are essential. By using feed-forward compensation techniques high-speed performance in these chips may be maximized. There are also quad 2-input OR gates (DM74LS86) which have four independent gates each of which performs the logic exclusive-OR function. There are 25 circuits.

Technical support and tech publications such as manuals and data sheets for the DS3800NGRC1H1F were originally provided by GE. These are still the best resource for installation guidelines.

Our sales team at AX Control is here to help you with anything automation related. If you don't see it on our website, please call or email us and we'll do our best to take care of it for you.

Repair Services For DS3800NGRC1H1F

Type Lead Time Price Action
Repair Service 1-2 weeks $322

Our highly skilled technicians can repair your DS3800NGRC1H1F. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
