The DS3800NGPA1B1C is a printed circuit board from GE

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a DS3800NGPA1B1C to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

DS3800NGPA1B1C

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
The DS3800NGPA1B1C is a printed circuit board from GE

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a DS3800NGPA1B1C to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Product Description

The DS3800NGPA1B1C is a PCB (printed circuit board) manufactured by GE as a gain programming card to fit into their Mark IV series. This series was created for gas or steam turbine management. It can automate some routines, including start-up and shutdown. It is also designed to keep the system from operating during unsafe or adverse conditions.

The DS3800NGPA1B1C accepts an optional auxiliary board (DS3800DBPA.) When this auxiliary is installed it gives the motherboard access to its six potentiometers and several PCB snap-in screw mounts. The auxiliary board will install on the right-hand side of the motherboard, where it will rest on four nylon pins and be held in place by twenty-nine board-to-board connectors.

The DS3800NGPA1B1C is alignment-marked and marked "NGPA 6DA08" and "6BA05." It has been drilled in all corners. Extractor clips are installed in the right-hand corners. Extractors help technicians with both insertion and extraction, especially in tight spaces, by giving the user an optional handle. They also can be used as a lever to pull the board out of its slot.

The DS3800NGPA1B1C has one amber LED and six red LEDs. These are in line with seventeen (TP) test points. The board is built with five transistors, one potentiometer, and multiple integrated circuits including dual operational amplifiers.

Multiple diodes, capacitors, and resistors (primarily ceramic metal film,) populate the DS3800NGPA1B1C. Capacitors include one 25v 50 μf (orange) capacitor.

Tech support for maintenance or installation, if needed for the DS3800NGPA1B1C, can be found by accessing publications such as datasheets or manuals from General Electric for this product.

Repair Services For DS3800NGPA1B1C

Type Lead Time Price Action
Repair Service 1-2 weeks $461

Our highly skilled technicians can repair your DS3800NGPA1B1C. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
