DS3800NFIA1B1B

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
GE Mark IV Board DS3800NFIA1B1B

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS3800NFIA1B1B to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800NFIA1B1B
  • SKU: DS3800NFIA1B1BGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

Product Description

The DS3800NFIA1B1B was created to be part of the Speedtronic Mark IV series of turbine controls. This board was produced by General Electric (GE). The DS3800NFIA1B1B is a printed circuit board, or PCB.

Many different circuit board components are featured on the DS3800NFIA1B1B printed circuit board (PCB). Located in the center of the top of the DS3800NFIA1B1B is connector port. A male connector is found inside the connector port. This connector port is identified as JA. Another smaller connector port is on one side of the DS3800NFIA1B1B. This small connector port is identified as JB and also has a male connector port. Thirty-two resistors are arranged in vertical lines in groups of four on the DS3800NFIA1B1B. Bands in varying shades of blue cover each resistor. These resistors are identified by the initial R, from R1 to R32. One (1) diode is located close to the lower side in the center of the DS3800NFIA1B1B. This diode is small and orange in color. This component is identified by the letters CR and is called CR1. Placed under the diode on the DS3800NFIA1B1B is a relay, sometimes known as a contactor. The relay is silver and shaped like a rectangle. This component is labeled by the letter K and is known as K1. The printed circuit board’s full part number, DS3800NFIA1B1B is marked on the top left side of the board. Printed along the left edge of the DS3800NFIA1B1B are the letters A to J. Also printed on the DS3800NFIA1B1B are the letters A through S.
