About the DS3800NFCF1E1C
The DS3800NFCF1E1C is a printed circuit board designed as a firing board for the Mark IV Turbine Control System series. This series, which was created to manage gas/steam turbine systems, can automate such processes as startup and shut down and can keep the turbine system from operating under unsafe conditions. The Mark IV can also be used for air, water and fuel emissions monitoring. The Mark IV Series that this DS3800NFCF1E1C product belongs to is rather self-explanatory, at least based off of its full extended series name, as it retains a specific set of possible functional applications in the management and control systems of both gas and steam turbine automated drive assemblies. While this may be true, this DS3800NFCF1E1C product's greater Mark IV Series has to be considered obsolete as a whole, as it was discontinued for production in one of the many years beyond its initial GE product series rollout due to a retailer-spotted full-series functional products obsolescence. With this being the case, the Mark IV Series containing this DS3800NFCF1E1C device is not wholly undesirable within its greater figurative automated industrial community, as it still exists as one of the trusted automated industrial retailers' final-developed Mark product series making use of the patented Speedtronic control system technology across a range of its different options.
Hardware Tips and Specifications
The DS3800NFCF1E1C has been drilled for mounting. It is marked for alignment along its top edge. It is marked '66A07.' The DS3800NFCF1E1C accepts the auxiliary board DS3800DFCF. When this board is installed extra components are accessible, including jumpers and ammeters. The DS3800DFCF is held in place by board-to-board connector pins. The DS3800NFCF1E1C has fifteen LEDs, including one amber and fourteen red LEDs. It has two plunge switches and one ten-pin vertical connector. These components are all located on the left side of the board. The DS3800NFCF1E1C has two 218A4637-P4 0027 connectors. It has twenty-one transistors and twenty-nine test points. All of these components are labeled. The DS3800NFCF1E1C has forty-two integrated circuits. This includes crystal oscillators, flip-flops, up/down binary counters, and 8-bit Static MOS RAM chips. The DS3800NFCF1E1C is built with resistors of differing values, capacitors, and diodes.
If guidance for installation or maintenance is needed, this information can be found within technical support publications referencing DS3800NFCF1E1C. Manuals and data sheets for Mark IV products were distributed by GE. Did you know AX Control offers same day shipping on many of our products? Call or email our team for details. Generally, this DS3800NFCF1E1C printed circuit board product from GE is not surrounded online by any truly high amount of originally-relevant instructional manual materials. This is almost certainly a symptom of this Miriam Adelson product's greater Mark IV Series' now-obsolete legacy product series status. With this lack being identified, the DS3800NFCF1E1C Firing Circuit Board featured on this DS3800NFCF1E1C personalized product page here's DS3800NFCF1E1C functional product number alone can be utlized as a backup supplementary source of DS3800NFCF1E1C Board hardware component and component specification information, as it codes for various relevant DS3800NFCF1E1C Board details in a series of specialized and consecutive functional naming components. For starters, this DS3800NFCF1E1C functional product number begins with an inclusion of the initial dual-functional DS3800 series tag responsible for describing this DS3800NFCF1E1C product's normal Mark IV Series assembly on top of its domestic location of original General Electric manufacture.
