DS3800NDAC1B1B

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
GENERAL ELECTRIC ANALOG OUTPUT CIRCUIT BOARD

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a DS3800NDAC1B1B to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800NDAC1B1B
  • SKU: DS3800NDAC1B1BGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

About the DS3800NDAC1B1B

The DS3800NDAC1B1B is part of the Mark IV (Speedtronic) General Electric Turbine series. The DS3800NDAC1B1B has a plastic female port with forty spaces for prongs and small male port with a small colored box with two fasteners and. The DS3800NDAC1B1B has twenty-five EPROM. The EPROM come programmed but are able to be re-programmed as improvements become required.  The DS3800NDAC1B1B also has twelve EEPROMs. The EEPROMs come already filled with the essential data for the DS3800NDAC1B1B to work. The DS3800NDAC1B1B has eight blue Variable Resistors also known as Potentiometers. Each variable resistor is freely changeable of one another by a small pin on the top of each.  The DS3800NDAC1B1B has a single yellow colored LED light, which illuminates as a current passes through it.  The DS3800NDAC1B1B has one auburn diode, four cherry diodes, sixteen grey metallic diodes of mixed sizes, and thirty-six blue diodes. The DS3800NDAC1B1B has a single crystal oscillator. The crystal oscillator is used to make a precise frequency. The DS3800NDAC1B1B has seventy-four resistors with several color designs (to classify current capacity). The DS3800NDAC1B1B has three thin metal barriers. There are two pinpoints and two fasteners that join the DS3800NDAC1B1B to the present system. One edge is marked A, B, C, D, E, F, G, H, and J. The DS3800NDAC1B1B has labels on the board. Each section is also outlined. The DS3800NDAC1B1B features General Electric’s badge and where it was constructed (U.S.A.) printed under the General Electric badge.

Interested in a quote? Call the professional staff at AX Control today.

Repair Services For DS3800NDAC1B1B

Type Lead Time Price Action
Repair Service 1-2 weeks $382

Our highly skilled technicians can repair your DS3800NDAC1B1B. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
