The DS3800NADB1B1B is a printed circuit board by GE

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a DS3800NADB1B1B to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

DS3800NADB1B1B

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
The DS3800NADB1B1B is a printed circuit board by GE

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a DS3800NADB1B1B to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Product Description

The DS3800NADB1B1B is a PCB manufactured by GE as part of their Speedtronic Mark IV line. The Mark IV, which was designed for gas and steam turbine control, has integrated chipsets with two-out-of-three voting redundancies on all critical controls and protection parameters. The Mark IV uses these intentional redundancies--or 'controlled failure' technology to plan for wear and repair of parts, but with as little downtime as possible.

The DS3800NADB1B1B functions as an analog/digital converter card. It is a larger board and has been designed as a motherboard to an optional auxiliary board (DS3800DADB.) When this auxiliary is installed the capacitance of DS3800NADB1B1B is increased through access to that board's eight capacitors ( 708A1 200V M/E .)

The DS3800NADB1B1B is built as follows:

  • There is one LED (amber.) The LED is labeled "p ok."

  • There are three test points (TPs.) These are labeled com/sync/aout.

  • There are three connectors for communicating with other boards: one female connector(218A4637-p2.) one male connector (218A45533-1 AMP) and one ribbon connector to communicate with its auxiliary board.

  • It is alignment marked.

  • It has extractor arms installed in two corners.

  • It is built with spare PTH for the addition of parts.

  • The board is built with multiple integrated circuits. This includes a 12-bit A/D converter with a clock. All digital signals from this chip are DTL/TTL compatible, and the data output is negative-true. It is available in either parallel or serial form.

Tech support for the DS3800NADB1B1B was provided by General Electric. Datasheets, manuals and other publications referencing installation instructions and maintenance schedules may be found through the original manufacturer.

Repair Services For DS3800NADB1B1B

Type Lead Time Price Action
Repair Service 1-2 weeks $306

Our highly skilled technicians can repair your DS3800NADB1B1B. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
