The DS3800HXRC1F1C is a printed circuit board by GE

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a DS3800HXRC1F1C to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

DS3800HXRC1F1C

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
The DS3800HXRC1F1C is a printed circuit board by GE

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a DS3800HXRC1F1C to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Product Description

The DS3800HXRC1F1C is a PCB created for use as a Series 6 receiver. The DS3800HXRC1F1C is part of the Speedtronic/Mark IV line from General Electric. This line was designed specifically for the control of gas and steam turbines. It is designed with integrated chipsets with built-in intentional redundancies that automatically redistribute and take on the responsibilities of a failed PCB before the entire system can be affected. In this way productivity of the entire system is maximized.

The DS3800HXRC1F1C acts as a motherboard for the auxiliary board DS3800DXRC. The two can be connected via a ribbon cable. This connects to a port located near the middle of the DS3800HXRC1F1C. This is one of four connectors populating the DS3800HXRC1F1C; the other three include a female connector on its left edge (218A44553-1AMP) and two male connectors along the opposite side. When connected to the auxiliary DS3800DXRC, the DS3800HXRC1F1C has use of 18 jumper switches and multiple integrated circuits located on that board.

The DS3800HXRC1F1C has 48 integrated circuits including DS74LS244N and DS74LS155N. It has two transistors located at Q1 and Q2. The board is marked 6BA03 and is marked for alignment along its upper edge. DS3800HXRC1F1C has been built with multiple jumper switches and resistor networks. It is factory drilled at all four corners. It has multiple resistors and capacitors.

Technical support including instructions for installation and maintenance was originally provided through the publication of data sheets and manuals from the manufacturer. We recommend using the information provided by GE that references the DS3800HXRC1F1C.

Repair Services For DS3800HXRC1F1C

Type Lead Time Price Action
Repair Service 1-2 weeks $474

Our highly skilled technicians can repair your DS3800HXRC1F1C. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
