GE Microprocessor Expander Board DS3800HXPD1D1E

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a DS3800HXPD1D1E to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

DS3800HXPD1D1E

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
GE Microprocessor Expander Board DS3800HXPD1D1E

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a DS3800HXPD1D1E to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Product Description

The GE Microprocessor Expander Board DS3800HXPD1D1E is designed for quick installation in the drive. The board features a modular connector on 1 end and retention levers on the other end. The GE Microprocessor Expander Board DS3800HXPD1D1E also is populated with 2 34-pin connectors between the retention levers. The board is also populated with 8 sockets for electrically erasable programmable read-only memory (EEPROM) modules and 18 jumpers.

The retention levers on the front of the GE Microprocessor Expander Board DS3800HXPD1D1E secure the board in the rack. The retention levers have a cam action that presses the board into the modular connector at the bottom of the board rack. The modular connector mates with a modulate connector attached to the board. The cam action presses the connectors together and ensure a tight and reliable connection. The modular connection carries control signals and the current to power the board. Some of the control signals are transmitted from the board after being processed. Other control signals are received by the board. They are received for processing.

The 2 34-pin connectors also receive and transmit signals. The connectors are fitted with retention clips. They slide over the connector and firmly hold the ribbon cable in position. Before you remove the ribbon cable, you must swing open the retention clips. Be sure the ribbon cable is routed carefully in the drive interior. Don’t let the ribbon cables block the air vents or let the ribbon cables block air from flowing over the components.

Repair Services For DS3800HXPD1D1E

Type Lead Time Price Action
Repair Service 1-2 weeks $395

Our highly skilled technicians can repair your DS3800HXPD1D1E. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
