DS3800HSPC1D1C

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.88 (16)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.88 (16)
  • Click a star to rate this product
This DS3800HSPC1D1C Speed Position Input Module was manufactured for General Electric's Mark IV Turbine Control System Series.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS3800HSPC1D1C to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800HSPC1D1C
  • SKU: DS3800HSPC1D1CGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

DS3800HSPC1D1C Technical Specifications

Original Manufacturer General Electric
Series Mark IV Speedtronic
Functional Part Number DS3800HSPC1D1C
Functional Description DS3800HSPC1D1C Speed Position Input Module

About the DS3800HSPC1D1C

The DS3800HSPC1D1C was made as a speed position input board. It was manufactured by GE and a component of the gas and steam turbine control system known as Speedtronic Mark IV.

Hardware Tips and Specifications

Very small components like capacitors, diodes and resistors are located on all 25 integrated circuits on the DS3800HSPC1D1C. Differing colors of capacitors are all over the board. A large number of the capacitors are black or light blue in color. One of the capacitors is yellow and 3 of them are silver. A single capacitor is covered in bands with different colors. Represented by the colored bands is the component’s energy capacity. Several resistors are also banded in various colors.

 The capacity of the device is represented by the bands on the resistors as well. The DS3800HSPC1D1C contains:

  • two transistors
    • first transistor called Q1 is shaped like a half-circle and is black
    • other transistors known as Q2 which is round and silver
  • many diodes which are banded in shades of red.
  • a series of test points bordering the right end of the board
  • A blue connector port
  • a few jumper pins
    • can be connected by a black jumper.

A potentiometer is on the right of the DS3800HSPC1D1C. A potentiometer is alternately called a variable resistor. This potentiometer is colored blue. A circuit board potentiometer like the one on the DS3800HSPC1D1C is used to change the variable resistor's resistance. Potentiometers are also used to control things like volume in other devices.


Frequently Asked Questions about DS3800HSPC1D1C

Would the DS3800HSPC1D1C here actually be available on any repair basis?

Yes. Our in-house technicians at AX would love to attempt a repair on your DS3800HSPC1D1C device here today.

Which revisions does the DS3800HSPC1D1C Speed Position Input Module incorporate?

Based off of the DS3800HSPC1D1C functional product number, this DS3800HSPC1D1C device has both D and C-rated functional revisions.

Reviews For DS3800HSPC1D1C

Internal Review
(5.0)

This DS3800HSPC1D1C device is a unique GE Mark product series offering, in that it exists as a Speed Position Input Module despite a certain mismatching with the HSPC functional product abbreviation as well as the DS3800 initial product tag asserting a normal PCB assembly. Either way, this DS3800HSPC1D1C device remains available for repair here today. - AX Control Lead Technician

Repair Services For DS3800HSPC1D1C

Type Lead Time Price Action
Repair Service 1-2 weeks $413

Our highly skilled technicians can repair your DS3800HSPC1D1C. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
