This DS3800HSHB Circuit Board was first designed for the Mark IV Turbine Control System Series of General Electric.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS3800HSHB to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800HSHB
  • SKU: DS3800HSHBGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

DS3800HSHB Technical Specifications

Original Manufacturer General Electric
Series Mark IV Speedtronic
Functional Description DS3800HSHB Circuit Board
Functional Part Number DS3800HSHB

About the DS3800HSHB

The DS3800HSHB is a circuit board made by General Electric to be part of the Speedtronic Mark IV series. Mark IV and its predecessor systems have been utilized for the safe and efficient operation of gas and steam turbines for decades.

Hardware Tips and Specifications

Thirty-one integrated circuits are featured on the DS3800HSHB. A number of various electrical components is found on each one of the integrated circuits. A useful ribbon cable may be found on the bottom edge of the board. A cable in which several wires run parallel to each other on a single flat surface, a ribbon cable is beneficial when an operator needs to make many connections but doesn't want a mess of wires. The DS3800HSHB has:

  • twenty-five resistor networks on its surface
  • a variety of small yellow capacitors, as well as silver capacitors
  • many banded resistors which feature various colors
  •  two blue connector ports
    • 218A4807-P12
    • 218A4807-P14
  • an empty space marked a SPARE
    • offers more space to connect extra components to the surface of the card

Situated on the right edge of the DS3800HSHB is a jumper link, which lets a user adjust the functions of the board. AX Control will ensure that each product meets our high standards of quality. For technical support, GE should be consulted. This DS3800HSHB Circuit Board device is more than likely available right here today for a repair, given its simple product makeup lacking any total Mark Series revision.
