DS3800HSCJ

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
The DS3800HSCJ Hi-Level Isolator Circuit Card was made first for General Electric's Mark IV Turbine Control System Series.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a DS3800HSCJ to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800HSCJ
  • SKU: DS3800HSCJGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

DS3800HSCJ Technical Specifications

Original Manufacturer General Electric
Series Mark IV Speedtronic
Functional Description DS3800HSCJ Hi-Level Isolator Circuit Card
Product Number DS3800HSCJ

About the DS3800HSCJ

Mark IV Series Hardware Details

General Electric manufactured the DS3800HSCJ to be a part of the Speedtronic Mark IV series which is used to regulate the operation of gas and steam turbines. The Mark IV system, as well as the earlier Mark systems, have been in use for decades since the development of the Mark I system in the 1960s. The technologies used in the Mark systems have been developed since the late 1940s.

The Mark IV system controls fuels in accordance with the requirements of speed or load control. The system controls temperatures and sequences auxiliaries for fully automated startup, shutdown and cool down. The Mark system also protects against adverse operating situations and operating conditions. The system can also monitor emissions of water, fuel, and air. DS3800HSCJ is a high level isolator circuit card. Isolator circuit cards are used to protect people, circuits, and equipment from shock and short circuits. These isolator cards can also eliminate group loops, protect circuits from faults, get rid of conducted noise and let safe and accurate measurements to be taken.


DS3800HSCJ Device Personal Hardware Specs

The DS3800HSCJ isolator circuit card contains a number of different circuit board components. A number of various diodes, resistors, capacitors, transformers and transistors can be found throughout the DS3800HSCJ. Each component is connected to the circuit through a series of traces etched into the surface of the board.

Technical support and troubleshooting for the DS3800HSCJ were originally provided by General Electric. This includes any manuals and data sheets. If technical support for the device is needed, General Electric should be consulted.


Frequently Asked Questions about DS3800HSCJ

Would this DS3800HSCJ device be at all considered a revised GE Mark IV Series offering?

No. This is not a revised GE Mark Series product offering, as the trailing digitless DS3800HSCJ product number seems to prove.

Does this DS3800HSCJ device have any specific GE Mark Series grouping?

No. This DS3800HSCJ device is not grouped within any specific GE Mark product series, although a basic assembly and Mark IV Series attribution would posit it well for a group one typical grouping.

Reviews For DS3800HSCJ

Internal Review
(5.0)

While it is not definable through any specific GE Mark IV Series product grouping or individual revision, this DS3800HSCJ device is still quite the highly-sought offering given a low general availability online. Additionally, the DS3800HSCJ device here as been designated as one crucial to the specific process or Hi-Lev Isolation, which specializes it further. Available in either new or reconditioned product quality. - AX Control Lead Technician

Repair Services For DS3800HSCJ

Type Lead Time Price Action
Repair Service 1-2 weeks $395

Our highly skilled technicians can repair your DS3800HSCJ. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
