GE Dom Plus Servo Amp Board DS3800HSAA1U1J

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a DS3800HSAA1U1J to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800HSAA1U1J
  • SKU: DS3800HSAA1U1JGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

DS3800HSAA1U1J

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.75 (4)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.75 (4)
  • Click a star to rate this product
GE Dom Plus Servo Amp Board DS3800HSAA1U1J

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a DS3800HSAA1U1J to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800HSAA1U1J
  • SKU: DS3800HSAA1U1JGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

Product Description

The GE Dom Plus Servo Amp Board DS3800HSAA1U1J features a modular connector on 1 end and retention levers on the other end. The board is populated with a heat sink. The analog/digital converter is a component embedded on the board. The GE Dom Plus Servo Amp Board DS3800HSAA1U1J is also populated with 1 34-pin connector and 1 socket for electrically erasable programmable read-only memory (EEPROM) modules. The board is also populated with 3 trimmer resistors.

The GE Dom Plus Servo Amp Board DS3800HSAA1U1J that is installed in the drive might be an early version of the board. The board is updated with the latest problem fixes and improvements. The improvement can encompass changes to the hardware components and updates to the circuits on the board. This can result in a newer version of the board having a different appearance. Components might be located in different locations or the components might look different or have a different shape.

Despite the differences, compatibility between the different versions of the same board is assured. This means that you can remove an older version and install a newer version and it will provide the same processing function. This is due to the extensive product testing performed to ensure compatibility.

Because the board is equipped with a heatsink to remove heat from a component, you must make sure that the board can remove heat before it builds up in the drive. Make sure cables are routed on the outer edge of the drive interior.



Repair Services For DS3800HSAA1U1J

Type Lead Time Price Action
Repair Service 1-2 weeks $468

Our highly skilled technicians can repair your DS3800HSAA1U1J. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
