DS3800HPTJ1C1C

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.93 (14)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.93 (14)
  • Click a star to rate this product
The DS3800HPTJ1C1C Gate Driver Card was manufactured by General Electric for the Mark IV Speedtronic Series.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS3800HPTJ1C1C to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800HPTJ1C1C
  • SKU: DS3800HPTJ1C1CGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

DS3800HPTJ1C1C Technical Specifications

Manufacturer General Electric
Series Mark IV Speedtronic
Part Number DS3800HPTJ1C1C
Functional Acronym HPTJ
Functional Description Gate Driver Card

About the DS3800HPTJ1C1C

The DS3800HPTJ1C1C is a very small circuit board from General Electric. The DS3800HPTJ1C1C is featured in the Mark IV Speedtronic line to control gas and steam turbines. The gas and steam turbines are a fast way to provide energy and flexible fuel. A gas turbine builds pressure by using a combination of air and fuel in an internal combustion engine to create a mixture of gases to turn the turbine blades. A steam turbine uses a large boiler which is filled with water. The boiler is then heated to create large amounts of steam which then turns the blades of the turbine. The energy produced by the spinning turbine blades is then harnessed for other purposes. The DS3800HPTJ1C1C has one large white capacitor that stores energy in an electrical field for the circuit board to use at a later time. The DS3800HPTJ1C1C has a male terminal port with ten prongs. The DS3800HPTJ1C1C has a large black box on the circuit board. The DS3800HPTJ1C1C has three small black diodes that only allow energy to flow in one direction through them. The DS3800HPTJ1C1C has three tiny silver circular transistor, which is used to amplify or alter electrical power or electrical signals.  The DS3800HPTJ1C1C has twelve large dark colored resistors and ten small light colored resistors. Resistors are used to restrict energy as it flows across the circuit board. The amount of energy each resistor can withstand can be figured out by the colored stripes around the outside that correspond with a code.

Please contact the trusted team at AX Control if you have any questions or would like a quote.

Repair Services For DS3800HPTJ1C1C

Type Lead Time Price Action
Repair Service 1-2 weeks $438

Our highly skilled technicians can repair your DS3800HPTJ1C1C. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
