GE Parallel Line Buffer Board DS3800HPBC1D1D

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a DS3800HPBC1D1D to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800HPBC1D1D
  • SKU: DS3800HPBC1D1DGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

About the DS3800HPBC1D1D

The GE Parallel Line Buffer Board DS3800HPBC1D1D is designed for quick installation in the drive. The board features a modular connector on 1 end and retention levers on the other end. The GE Parallel Line Buffer Board DS3800HPBC1D1D also is populated with 1 red indicator LEDs and 2 amber LEDs which are visible from the front of the board. The board also is populated with 3 jumpers, and multiple capacitors.

Another component on the board is a transistor to transistor logic (TTL) device. It serves as the interface logic between integrated circuits.

The GE Parallel Line Buffer Board DS3800HPBC1D1D is installed in a drive that has several requirements for the installation site you choose. Dirt, dust, and harsh chemicals can shorten the life expectancy of the board. When you select the installation site, choose a location with clean air that has a minimum of dirt and dust.  Refer to an installation specification about the chemicals that the drive can be near during operation.

If the harsh chemicals can potentially harm the drive, there are several steps to consider to mitigate the situation. Ventilation hoods can be installed over the drive. The hoods use powerful fans to remove all chemicals, dirt, and dust from the air. It can improve working conditions of the drive. Filters can be installed to remove the harsh chemicals from the air. The filters are part of the ventilation system and they can remove dust and dirt from the air. Another solution is to install the drive in another room that is free of the harsh chemicals.

Repair Services For DS3800HPBC1D1D

Type Lead Time Price Action
Repair Service 1-2 weeks $312

Our highly skilled technicians can repair your DS3800HPBC1D1D. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
