Product Description

The DS3800HDRC1A1A circuit board by General Electric (GE) was created as a part of the Speedtronic Mark IV turbine control series. The DS3800HDRC1A1A circuit board is a line driver/receiver circuit board.

A line driver circuit board is a type of electronic amplifier circuit that is made to drive a load, for example a transmission line.

The DS3800HDRC1A1A circuit board contains twenty-four (24) black integrated circuits labeled U1 through U24. There are twenty-five (25) small yellow capacitors scattered around the entirety of the board. There is also one (1) larger silver capacitor and one (1) larger orange capacitor. The board has two (2) 218A4637-P4 blue jack connector ports labeled with JA and JB along one edge of the board. In between the two (2) connector ports are two test points labeled with TP1 and TP2. The DS3800HDRC1A1A also has twenty-six (26) small multicolored striped resistors. Located along one of the edges of the board is a long black connector port labeled with the numbers ten (10) through eighty (80) in increments of ten. The circuit board also has two (2) red jumpers labeled as J1 and J2. The circuit board is marked on the top edge with the letters A through J.

The Mark IV system is the product of many years of the innovation and improvement of technologies dating back decades.

The DS3800HDRC1A1A line driver/receiver circuit board will be packaged by AX Control in a way which will dissipate any energy before opening. Troubleshooting and technical support for the DS3800HDRC1A1A would be provided by General Electric.
