DS3800HCMA1F1G

About the DS3800HCMA1F1G

The GE Dual Communications Control Board DS3800HCMA1F1G features a modular connector for attachment to a drive and retention levers to hold the board in the drive. The GE Dual Communications Control Board DS3800HCMA1F1G also is populated with 20 jumpers, and 1 amber and 2 red indicator LEDs. The board also has 2 34-pin connectors, and multiple capacitors.

The GE Dual Communications Control Board DS3800HCMA1F1G is one of multiple boards designed to be be compatible with the drive. The boards must meet a specific common design standard so that they can be installed in the drive and process signals. The board is populated with a modular connector at the rear that fits into a matching modular connector at the bottom the board rack. The modular connector supplies the board with the proper electrical current to power the operation of the board. It also supplies the means to transmit and receive the command signals that the board processes during normal operation.

The top of the board has retention levers that secure the board in the drive. It holds the board in place so that the modular connectors remain securely connected.

The GE Dual Communications Control Board DS3800HCMA1F1G is populated with 3 indicator LEDs. The LEDs are located between the retention levers and are adjacent to the 34-pin connectors. The operator can easily view them and monitor the health and activity of the board. When the red LEDs are lit, it indicates that an error has occurred. When the amber LED is lit, it indicates that an alert has occurred.
