GE Regulator Board DS3800HAIC1B1A

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a DS3800HAIC1B1A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800HAIC1B1A
  • SKU: DS3800HAIC1B1AGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

DS3800HAIC1B1A

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.75 (4)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.75 (4)
  • Click a star to rate this product
GE Regulator Board DS3800HAIC1B1A

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a DS3800HAIC1B1A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800HAIC1B1A
  • SKU: DS3800HAIC1B1AGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

Product Description

The GE Regulator Board DS3800HAIC1B1A features a modular connector for attachment to a drive and retention levers to hold the board in the drive. The GE Regulator Board DS3800HAIC1B1A also is populated with 9 jumpers, and 2 trimmer resistor components. The board also has 1 20-pin connector and several test points.

The test points have IDs that are useful when you want to test the circuits on the board. The test points enable a technician to test the circuits on the board. Each test point is part of a circuit and tests specific functionality. The qualified servicer might have need to refer to service documentation concerning the board. The service documentation describes each circuit and also includes a diagram of the board. The IDs used to describe the test points in the service document will match the IDs you see printed on the surface of the board. The IDs do not contain a standard prefix but instead describe the purpose of the circuit. For example, some of the IDs are CLK, DV, DB, JAT, and JBT.

When you find the test point you want to test for the specific function, first disconnect the ribbon cables attached to the board and pull up on the retention levers. Use the levers to pull the board out of the board rack and place it immediately on a dry, clean and sturdy surface. The qualified servicer will have the proper testing equipment to perform the task. Throughout the procedure the servicer must wear a wrist strap to protect against static build up.




Repair Services For DS3800HAIC1B1A

Type Lead Time Price Action
Repair Service 1-2 weeks $347

Our highly skilled technicians can repair your DS3800HAIC1B1A. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
