GE Mark IV Printed Circuit Board DS3800HADA1A1A

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a DS3800HADA1A1A to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

DS3800HADA1A1A

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.75 (4)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.75 (4)
  • Click a star to rate this product
GE Mark IV Printed Circuit Board DS3800HADA1A1A

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a DS3800HADA1A1A to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Product Description

The GE Mark IV Printed Circuit Board DS3800HADA1A1A features multiple pins that are connected through fine wires wrapped around the pins. The GE Mark IV Printed Circuit Board DS3800HADA1A1A also is populated with 8 jumpers for configuring the board and 1 decoder/demultiplexer.

The decoder/demultiplexer processes signals on the board and combines several signals into 1 signal for transmission. The decoder/demultiplexer cannot be configured.

The jumpers are 1 means of configuring the board.  Best practice is to configure the board before you install it in the drive. The qualified installer must consult with the engineers at the site and review the configuration options available with the jumpers. The jumpers come from the factory set at the default positions. These are typically the most commonly used configuration settings. Also, included with the board is a set of configuration instructions that detail the jumpers and how moving the pins changes how the board behaves.

Once the installer has consulted with the operators and engineers, it is easy to move the jumpers. Just before you plan to move the jumpers and install the board, open the static-protective bag and slide out the board. Place the board on top of the bag. Then, locate the jumpers to move by referring to the jumper IDs. The jumper identifiers begin with the letter J. Use your thumb and 1 finger to pull up on the jumper to remove it. Alternatively, use a small set of pliers or other instrument to pick up the jumper. Slide it over the pins you want to cover.




Repair Services For DS3800HADA1A1A

Type Lead Time Price Action
Repair Service 1-2 weeks $438

Our highly skilled technicians can repair your DS3800HADA1A1A. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
