Product Description

The GE Circuit Board DS3800DSWA1A1A is 3 inches in height and 5 inches in length.  The board features 12 trimmer resistors, multiple capacitors, and 12 jumpers. The GE Circuit Board DS3800DSWA1A1A also is populated with 1 34-pin connector.

The ribbon cable provides the means by which the board receives signals from other boards in the drive. It also enables the board to send signals to other boards. The drive is populated with multiple boards that perform the processing for the drive. Signals are received by each board for processing. Then, after processing, the signals are sent to other boards for further processing. The 34-pin ribbon cable also provides the current required to power the board. The 34-pin ribbon cable is easily damaged so it requires some special consideration.

The plastic connector attached to the end of the ribbon cable contains the 34 separate strands of wire but they are easily disconnected from the connector. To avoid damage, always disconnect the ribbon cable by holding the plastic connector and not the ribbon cable. Carefully pull it out without putting stress on the cable.

This is also true when you remove the board. Do not tug the cable out of the connector by pulling on the board. When you attach the ribbon cable, also use best practices. Align the connector and use your thumb and 1 finger to press it into to place. Visually inspect it to find space between the connectors. If you find space, press the connectors again until the ribbon cable is fully seated.



Repair Services For DS3800DSWA1A1A

Type Lead Time Price Action
Repair Service 1-2 weeks $339

Our highly skilled technicians can repair your DS3800DSWA1A1A. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
