GE Circuit Board DS3800DRRA1C1B

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS3800DRRA1C1B to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800DRRA1C1B
  • SKU: DS3800DRRA1C1BGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

About the DS3800DRRA1C1B

The GE Circuit Board DS3800DRRA1C1B is 2 inches in height and 5 inches in length. The board features 6 terminals with retention screws, multiple capacitors, and 3 jumpers. The GE Circuit Board DS3800DRRA1C1B also is populated with 16 single-pin connectors and 5 resistors embedded on the board.

The GE Circuit Board DS3800DRRA1C1B is populated with terminals so that a qualified technician can add components to the board. This allows the board to be configured to the exact needs of the drive. Since this is a highly technical task that requires a thorough knowledge of the board and the components, only a qualified technician should add components. The components must be added only before the board is installed in the drive. Place the board on a flat surface that is free of debris, dust, and dirt. Under the board place a flattened static protective bag so that static can not enter the board from the work surface. Also, the technician must wear a wrist strap. This provides a means for the static on your person and the board to drain to the grounded surface the strap is attached to. One end of the strap is  attached to your wrist and the other end is a clip that you can attach to a metal surface, like a metal chair or desk leg.

Use a screwdriver to open the tops of both terminals and insert the lead wires. Tighten the terminals with the screwdriver. Use the information supplied with the board to learn what circuits the terminals are part of.

Repair Services For DS3800DRRA1C1B

Type Lead Time Price Action
Repair Service 1-2 weeks $336

Our highly skilled technicians can repair your DS3800DRRA1C1B. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
