The GE MD Exciter Control Board DS3800DMEC1D1D features 7 terminals for attaching additional components to the board, and 2 indicator LEDs. The GE MD Exciter Control Board DS3800DMEC1D1D also is populated with 14 trimmer resistors, 20 jumpers, 1 20-pin ribbon cable, and 1 34-pin ribbon cable.
The GE MD Exciter Control Board DS3800DMEC1D1D is engineered to be installed in a drive that is attached to a wall or other vertical surface. There are several factors to keep in mind when you install the drive that will improve the reliability of the board and lead to a longer life span for the board.
Before you select the location for the drive plan for the power cabling. The main power supply must be equipped with an emergency shut off so that the high-voltage power can be removed instantly. This might reduce injury to individuals or reduce damage to the drive or other equipment in the area. The location you have chosen must also be free of moisture on the floor or puddle of water or other liquid. If the area is prone to condensation or other sources of moisture, use dehumidifiers or other means of keeping the area dry.
Make sure you route and install the proper signal cabling the drive will need. You will also need to have an electrician or an engineer install the high-voltage power supply cabling. This will also include inverters to transform ac current to dc current, if the drive requires dc current for your site.
