GE Div Multi Auxiliary Board DS3800DDMA1A1A

AVAILABILITY:

IN STOCK
SHIPS TODAY

3 Year Warranty: Learn More
Sell Surplus: Have a DS3800DDMA1A1A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800DDMA1A1A
  • SKU: DS3800DDMA1A1AGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

DS3800DDMA1A1A

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.75 (4)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.75 (4)
  • Click a star to rate this product
GE Div Multi Auxiliary Board DS3800DDMA1A1A

AVAILABILITY:

IN STOCK
SHIPS TODAY

3 Year Warranty: Learn More
Sell Surplus: Have a DS3800DDMA1A1A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800DDMA1A1A
  • SKU: DS3800DDMA1A1AGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

Product Description

The GE Div Multi Auxiliary Board DS3800DDMA1A1A features 20 single pin connectors and 7 trimmer resistors. It also is populated with terminals for attaching components, such as resistors or capacitors. The GE Div Multi Auxiliary Board DS3800DDMA1A1A serves as daughter card that adds capacity or functionality to another board in the drive. If you decide to replace the board, it is best practice to remove the GE Div Multi Auxiliary Board DS3800DDMA1A1A and the board to which it is connected.

The daughter card is populated with the functionality designed to bolster the processing and resources of the board it is connected to.

When you are ready to adjust the trimmer resistors, there are several considerations to keep in mind. The IDs assigned to the trimmer resistors are printed on the surface of the board. To adjust the trimmer resistors, use a tester device to gauge the signals produced by the circuit the trimmer is assigned to. When the signals are at the level you expect, you are finished adjusting the trimmer.

Other configuration settings are made to the board by moving the jumpers on the board. The board has 2 jumpers. The ID of 1 jumper is JP1 and the ID of the other jumper is JP2. The jumpers are 3-pin jumpers which describes the number of pins associated with the jumpers. You can insert the jumper over pins 1 and 2 or pins 2 and 3. The board will process differently depending on which pins are covered by the jumper.



Repair Services For DS3800DDMA1A1A

Type Lead Time Price Action
Repair Service 1-2 weeks $468

Our highly skilled technicians can repair your DS3800DDMA1A1A. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
