Product Description

The IC3600TRLH1B1 is a GE FANUC component for both the Mark I and the Mark II series.  These two series were both designed to manage heavy-duty gas/steam turbines. They share many of the same components and features, although the MKI has standard GT wiring while the MKII has GT ring bus wiring, the MKI has a standard overspeed bolt while the MKII’s is optional, and the MKI has a separate TX meter while the MKII does not.  These are only some of the minor differences between these two systems. Both the MKI and MKII were created to provide the turbine user with the highest degree of reliability, performance, and adaptability possible using the technology available. Both systems are now obsolete. They have been replaced by newer Speedtronic systems (most recent being the MKVIe.)

The IC3600TRLH1B1 is built with components marked TP1 through TP4.  It has capacitors of several materials, including ceramic, polyester vinyl, and aluminum electrolytic.   Resistors are usually mounted vertically. These may be metal film or carbon composite. Diodes are also usually mounted vertically.

The IC3600TRLH1B1 has a single potentiometer.  There are more than twenty transistors of multiple designs.  The board uses several examples of surface wiring.

Like most MKI/MKII boards, the IC3600TRLH1B1 has a single edge populated with right-angled metal pins over numbering.  These pins act as a single communications component.

You can buy from AX Control with confidence.  If an item from AX Control is found to be defective through normal wear and use and is within the three year warranty period, AX Control will refund, repair, or replace your item with an identical product.  Please see our warranty page for more information, or speak to your sales representative.

Repair Services For IC3600TRLH1B1

Type Lead Time Price Action
Repair Service 1-2 weeks $293

Our highly skilled technicians can repair your IC3600TRLH1B1. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
