DS215UCVBG1A

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
General Electric's DS215UCVBG1A is a printed wiring board from the LS2100 Series. This model is one of two DS215UCVBG models, with up to 16M of DRAM. This model comes equipped with a MicroGeni and IV-586 board.

AVAILABILITY:

IN STOCK
SHIPS TODAY

3 Year Warranty: Learn More
Sell Surplus: Have a DS215UCVBG1A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS215UCVBG1A
  • SKU: DS215UCVBG1AGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: LS2100 & LS2100e Static Starter Control

DS215UCVBG1A

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
General Electric's DS215UCVBG1A is a printed wiring board from the LS2100 Series. This model is one of two DS215UCVBG models, with up to 16M of DRAM. This model comes equipped with a MicroGeni and IV-586 board.

AVAILABILITY:

IN STOCK
SHIPS TODAY

3 Year Warranty: Learn More
Sell Surplus: Have a DS215UCVBG1A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS215UCVBG1A
  • SKU: DS215UCVBG1AGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: LS2100 & LS2100e Static Starter Control

DS215UCVBG1A Technical Specifications

Flash Memory 4M
Hardware MicroGeni, IV-586, and DS200UCVAG1 Board
Manual GEH-6371
Number of DLAN+ Ports One
Series LS2100
VME Slot Occupation 2

Frequently Asked Questions about DS215UCVBG1A

What are some features of the DS215UCVBG1A model?

Some features of the DS215UCVBG1A board are a Genius LAN port, one DLAN+ port, and 16M of DRAM.

What is the standard hardware of the DS215UCVBG1A model?

The DS215UCVBG1A board is made up of one MicroGeni board, one IV-586 board, and one DS200UCVAG1 board.

Are there any special notes that should be taken into account when operating the DS215UCVBG1A model?

Yes! The DS215UCVBG1A board requires forced air cooling of the VME rack when being operated.

What is on the faceplate of the DS215UCVBG1A board?

On the faceplate, there is a top extractor and a bottom extractor, as well as many different ports. For information on what the DS215UCVBG1A faceplate looks like refer to figure 3-8 within the GEH-6371 Unit Controller 2000-VME User's Guide.

Are there any jumpers within the DS215UCVBG1A board?

Yes, there are BERG jumpers within the JP2 and JP1 sections of the DS215UCVBG1A model.

Product Description

The DS215UCVBG1A model is a printed wiring board part of the LS2100 Series from General Electric. The model features one Genius LAN port, one 10base2 Ethernet port, and 4M of flash memory. The primary purpose of this model is to replace a PLC model that is typically used with the Load Commutated Inverter Control Series. Another feature within the model is a 586-133 Pentium Processor, one DLAN+ port, and 16M of DRAM.

When the DS215UCVBG1A model is being powered up there are several power requirements the power requirements on this model are greater than that of the DS215UCVAG models. This model requires a negative twelve volts of direct current at approximately 200 mA when at its peak, positive five volts of direct current at approximately 5.64 mA when at its peak, and a positive twelve volts of direct current at approximately 900 mA when operating at peak.

The DS215UCVBG1A model is not widely available on the market but can still be found. Here at AX Control INC, we offer both new and refurbished models from our surplus inventory. If you have any questions regarding how to use this model you can contact us or browse through the GEH-6371 Unit Controller 2000/VME User’s Guide.

Reviews For DS215UCVBG1A
Internal Review

General Electric UCVA DS215UCVBG1A model is used within the VME rack for the LS2100 Series. When operating the model within the VME rack it requires forced air cooling through auxiliary fans. - AX Control Technician

Repair Services For DS215UCVBG1A

Type Lead Time Price Action
Repair Service 1-2 weeks $1285

Our highly skilled technicians can repair your DS215UCVBG1A. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
