DS215UCVAG1A

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.33 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.33 (3)
  • Click a star to rate this product
The General Electric UCVA Board DS215UCVAG1A is a printed wiring board as part of the LS2100 Series. This model has an abundance of features and is one of four. This model has the ability to hold up to 4M of flash memory.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a DS215UCVAG1A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS215UCVAG1A
  • SKU: DS215UCVAG1AGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: LS2100 & LS2100e Static Starter Control

DS215UCVAG1A

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.33 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.33 (3)
  • Click a star to rate this product
The General Electric UCVA Board DS215UCVAG1A is a printed wiring board as part of the LS2100 Series. This model has an abundance of features and is one of four. This model has the ability to hold up to 4M of flash memory.

AVAILABILITY:

CALL FOR AVAILABILITY

3 Year Warranty: Learn More
Sell Surplus: Have a DS215UCVAG1A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS215UCVAG1A
  • SKU: DS215UCVAG1AGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: LS2100 & LS2100e Static Starter Control

DS215UCVAG1A Technical Specifications

Alphanumeric Catalog Number DS215UCVAG1A
DRAM Quantity 8M
Flash Memory 4M
Functional Acronym/Abbreviation UCVA
Number of Genius LAN Ports 1
Parts Manual GEH-6371
Quantity of DLAN+ Ports One

Frequently Asked Questions about DS215UCVAG1A

Is the DS215UCVAG1A board equipped with flash memory?

Yes, it has flash memory SIMM and is furnished on all UC2000V modules. This model is specifically found within the primary position of the DS215UCVAG3 models.

How many VME slots does the DS215UCVAG1A occupy?

The DS215UCVAG1A only occupies two VME slots, both of these slots must have a P1 connector.

What are the power requirements needed to properly run the DS215UCVAG1A board?

Depending on the current there is a different mA needed, if the power is at a positive five VDC the approximate power will be 3.3m while whether or not at a positive or negative twelve VDC the approximate power will be 85 mA.

Where can I find information on the DS215UCVAG1A board?

All information regarding this model can be found in the GEH-6371 Unit Controller 2000-VME User's Guide. The manual is attached under the manuals tab above.

What do I do if the DS215UCVAG1A board I am using starts exhibiting errors?

If the DS215UCVAG1A board you has starts to decrease in performance it is wise to remove the board and replace it. If you feel as if the board does not need to be replaced but only repaired AX Control offers repairs.

Product Description

The DS215UCVAG1A Board contains a processor that replaces a PLC for Load Commutated Inverters using the Innovation Series Controllers. There is an abundance of features within the UCVA model, which include but are not limited to, one 10base2 Ethernet port, 8M of Dram, a 486DX4-100 Processor, and one DLAN+ port. This model has the following hardware, one MicroGeni board, one IV-486 board, and one DS200UCVAG1 board.

The power requirements needed to operate the DS215UCVAG1A model are -12 VDC at roughly 85 mA at its peak, +5 VDC (plus or minus five percent) at roughly 3.3 A, and +12 VDC at roughly 85 mA at its peak. This model occupies several slots within the VME rack within the Control Cabinet which enables it to operate the drive. If your board begins to experience problems there is a reset switch located on the faceplate.

The DS215UCVAG1A board is mostly obsolete as it is no longer produced by General Electric Industrial Systems. The model can sometimes be found new and used, and we here at AX Control INC offer refurbished models as well. If you have any questions regarding this model, please don't hesitate to contact us at sales@axcontrol.com or by phone at (919) 372-8413.

Reviews For DS215UCVAG1A
Internal Review

The DS215UCVAG1A model has very little information on it but some information can be found within the GEH-6371 Unit Controller 2000/VME Users Guide. - AX Control Technician
