Product Description

The 193X801DAG01 is a PCB component manufactured by General Electric for DC drive systems such as the SCR Drive, the Speed Variator Drive, and compatible drive systems.  These systems use a DC motor and often use a separate operator station with a remote enclosure with speed adjust, run/start/stop control that provides the operator with basic command functions.  This operator station connects to the unit’s power and control unit.

The 193X801DAG01, like many of the PCBs in this series, is built with a front panel designed with a handle to facilitate easy installation and removal from rack systems.  This panel includes such information as the board ID number, its use (Coordination/Signal Amplifier/Linear Time,) and the General Electric circular logo. The board has two rotary dials and two round closed tabs.  These are labeled “P-426, response, P-440, and time adjust. The front panel and the PCB connect together using two screws.

The 193X801DAG01 is populated with two rotary-type potentiometers.  These align with the rotary dials on the front panel. It also has six electrolytic capacitors, and four other capacitors, including a poly-vinyl capacitor, marked 210B1C205K 2.0 +/- 10% 200V and another capacitor marked 4MFD 350W VDC. The board also has four transistors and a number of resistors of varying size and resistance. These resistors are made of carbon composite material. Diodes tend to be ceramic.

Our sales team will be happy to answer any questions about shipping options or any of our warranty or repair programs.   The 193X801DAG01 will be shipped in a protective, anti-static sleeve.
