The 193X543ADG02 is a circuit board created by GE. It functions as a PC board and TD relay.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 193X543ADG02 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

193X543ADG02

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
The 193X543ADG02 is a circuit board created by GE. It functions as a PC board and TD relay.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 193X543ADG02 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Product Description

The 193X543ADG02 is a GE 193x board that functions as a time delay circuit board.  The board was designed by General Electric as part of the 193X family of exciter replacement cards.  These circuit boards are designed to be used within a number of different drives and exciters from General Electric.

The 193X543ADG02 is built with two identical relay components mounted on the back edge of the board.  These relays can be programmed by the user to energize via a time delay function.   These delays can be set for different time ranges between 0.1 seconds to 60 seconds.  The board has two LED components located on the opposite board edge that illuminates when the relay is energized.

The 193X543ADG02 is a nearly square circuit board with multiple components.  Like most 193x boards it does not have a separate backplane connector but instead has integrated conductive points located on the back edge of the board that function as a backplane.

Other board components include wire jumpers, transistors, potentiometers, resistors, diodes, and capacitors.  There are also several integrated circuits.  Components may be mounted to the board vertically or horizontally.

The board has a barcode installed on one board edge.  It has several codes including the board ID.    Installation procedures should be carefully reviewed before handling or installing this equipment.   These can be found within OEM publications like manuals, user guides, and data sheets.
