The 193X272AAG01 is a General Electric Interconnect Board. This board is designed to foster interconnections between larger boards using its backplane connector and its onboard connector. While this board is no longer available through the original equipment manufacturer, it can typically be sourced from AX Control’s in-stock products.
The 193X272AAG01 is not designed with an attached faceplate due to its size and use within the associated General Electric system. It has two factory-made drill-holes located on one board edge to allow for mounting to a larger board using screws and standoffs. The Interconnect board will typically communicate with this board using a ribbon cable plugged into its one vertical pin connector and held in place with the single plastic clip located close by. The board will communicate with another device using the backplane located on the opposite board edge. This backplane is designed from multiple conductive tabs.
The 193X272AAG01 is marked with its board id number and may have additional codes, but does not carry any other components. Please refer to GE datasheets or manuals for detailed information regarding handling and installation, as these documents will provide the most accurate and thorough descriptions.
