General Electric 193X262AAG01 Gate Control Card

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 193X262AAG01 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 193X262AAG01
  • SKU: GBTC-18362
  • Manufacturer: GE Boards & Turbine Control
  • Series: 193x Boards

193X262AAG01 Technical Specifications

Manufacturer GE General Electric
Part Number 193X262AAG01
Series 193X Boards
Weight 10 lbs
Connectivities 12 Small Gray
Resistors Many
Transistors 12
Capacitors 5

About the 193X262AAG01

General Electric 193X262AAG01 Gate Control Card

  • Function: This is a gate control card, functioning as a printed circuit board (PCB).

  • Manufacturer & Series: Developed by General Electric (GE) for their 193X series.

  • Physical Characteristics: A large, square printed circuit board.

  • Components:

    • Connectivity: Twelve (12) small gray components are lined up along the left edge, possibly for plugging in other devices.

    • Resistors:

      • Many solid black resistors are distributed across the board.

      • Thirteen (13) solid black resistors are aligned in a row near the right edge.

      • Approximately twenty-five (25) solid black resistors are aligned parallel to the first row of resistors.

      • A brown resistor with red, orange, white, and brown bands is located on the far left side.

    • Transistors: A line of twelve (12) small solid black transistors is situated between the two rows of resistors.

    • Integrated Circuits (ICs):

      • Ten (10) solid black, rectangular ICs are present.

      • They are arranged in one row of six (6) and one row of four (4).

      • Each IC contains a self-contained network of very small components, and their part numbers are printed on the outside.

    • Capacitors:

      • Five (5) solid yellow capacitors are positioned on the board.

      • Two (2) of these are large, while the others are much smaller.

      • The voltage and part number for each capacitor are printed in black writing on its exterior.

Reviews For 193X262AAG01

Internal Review
(5.0)

The General Electric 193X262AAG01 is identified as a gate control card, a specialized printed circuit board (PCB) designed for GE's 193X series. Its large, square form factor suggests it's a significant component within a larger system. The board's layout and component density indicate a focus on precise control and signal processing. It features a considerable number of solid black resistors, arranged in distinct rows, suggesting a role in managing current flow and voltage division. Complementing these are twelve small solid black transistors, likely involved in switching or amplification, strategically placed between the resistor rows. A prominent aspect of the 193X262AAG01 is the inclusion of ten solid black, rectangular integrated circuits (ICs). These ICs, arranged in rows of six and four, are critical as they each contain a self-contained network of smaller components, implying complex logic or control functions. The clear printing of part numbers on these ICs, along with the voltage and part numbers on the five solid yellow capacitors (two large, three smaller), speaks to a design that prioritizes ease of identification and maintenance. The presence of gray components along the left edge suggests potential plug-in points for external devices or connections. In summary, the General Electric 193X262AAG01 appears to be a densely packed and highly specialized gate control card. Its array of resistors, transistors, and particularly the numerous integrated circuits, points to its function as a critical control element within a GE drive system. The clear labeling of components further enhances its serviceability. —AX Control Technicians

Repair Services For 193X262AAG01

Type Lead Time Price Action
Repair Service 1-2 weeks $347

Our highly skilled technicians can repair your 193X262AAG01. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
