193X241AAG01 circuit board manufactured by General Electric

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 193X241AAG01 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 193X241AAG01
  • SKU: GBTC-13182
  • Manufacturer: GE Boards & Turbine Control
  • Series: 193x Boards

193X241AAG01 Technical Specifications

Manufacturer GE General Electric
Part Number 193X241AAG01
Series 193X Boards

About the 193X241AAG01

The 193X241AAG01 is a circuit board produced by General Electric. The 193X241AAG01 has three large black wired ended electrolytic capacitors, four small yellow polypropylene capacitors, two large yellow polypropylene capacitors, one huge yellow polypropylene capacitors, and four large vibrant blue PCB Mount Electrolytic Capacitors. The 193X241AAG01 has eleven metal eye hooks around the circuit board. The 193X241AAG01 has nine dark-colored resistors that have stripes on the outside. The 193X241AAG01 has four thick grey wires with red ends attached to the circuit board. The 193X241AAG01 has a faceplate with three white knobs on it. The first knob reads Regen. Loss, the second knob reads Max. Positive, the third knob reads Max. Negative. The faceplate has the part number (193X241AAG01) and General Electric’s company symbol printed on the front. Capacitors are used to store additional energy in an electrical field that they create. Each capacitor has the storage capacity printed on the side. Striped resistors are used to restrict energy. The stripes on the resistors are part of a code. Each color corresponds with a numerical value that is used to calculate the amount of energy each resistor can restrict. Each component is outlined and has a number value next to it.

Looking for a quote or more information? Please call the skilled and friendly staff at AX Control for all of your automation needs.

**General Electric has provided the initial technical support. The staff at AX Control recommends referring to the original manufacturer's manual for safety procedures and instruction on how to install the part.

Frequently Asked Questions about 193X241AAG01

What types of capacitors are on the 193X241AAG01 board?

The 193X241AAG01 board features a variety of capacitors, including:
  • 3 large black wire-ended electrolytic capacitors
  • 4 small yellow polypropylene capacitors
  • 2 large yellow polypropylene capacitors
  • 1 huge yellow polypropylene capacitor
  • 4 large vibrant blue PCB Mount Electrolytic Capacitors

What is the function of capacitors on this board?

Capacitors are used to store additional energy in an electrical field they create. This stored energy can then be released to the circuit as needed. You can typically find the storage capacity printed on the side of each capacitor.

Are there any special mounting features on the board?

Yes, the 193X241AAG01 has 11 metal eye hooks located around the perimeter of the circuit board, which likely serve as mounting points.

What kind of resistors are on the board, and what do they do?

The board has 9 dark-colored resistors that have stripes on the outside. These are "striped resistors," which are used to restrict the flow of electrical energy (current). The stripes are a color code, where each color corresponds to a numerical value used to calculate the amount of energy the resistor can restrict.
