193X208AAG01

About the 193X208AAG01

• The 193X208AAG01 is a multipurpose module coordinator manufactured by General Electric.

Resistors

• Eighteen small dark brown resistors with colored stripes (code indicates numeric value for energy restriction).
• One large dark brown resistor with colored stripes (code indicates numeric value for energy restriction).
• Four small silver power resistors: Designed to withstand and dissipate large amounts of power.

Transistors

• Seven small black transistors: Purpose is to amplify or alter electrical or electronic signals.

Diodes

• Four small orange and black diodes: Semi-conductive devices with two terminals, typically allowing energy current to flow in one direction.

Capacitors

• One large PCB Mount Electrolytic capacitor.
• Two large yellow capacitors.
• One small yellow capacitor.
• Six small light blue capacitors.
• Function: Each capacitor creates its own electrical field to store additional energy for later circuit board use.
• Labeling: Each capacitor has its energy capacity written on its exterior.

Front Panel Features

• Four white knobs: Labeled from left to right as:
  • Timing Adj
  • IR Comp
  • Stability
  • Resp
• Each knob has an arrow indicating direction of turn.
• One white handle: To assist in proper placement of the circuit board.
