151X1233DD01SA01R3

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
The 151X1230BR02SA02 Charger Board from GE Energy

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 151X1233DD01SA01R3 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 151X1233DD01SA01R3
  • SKU: GBTC-59371
  • Manufacturer: GE Boards & Turbine Control
  • Series: 151X Boards and Modules

151X1233DD01SA01R3 Technical Specifications

Part Number 151X1230BR02SA02
Functional Description Charger Board
Software RC2G
Output 12VDC/2A
Input 230VAC/.5A
Screw Standoffs 5 Standoffs
Plugs PL1-PL3
Fuses FU1-FU3

About the 151X1233DD01SA01R3

The 151X1230BR02SA02 Charger Board from GE Energy was customized to act in its functional role through a series of hardware additions. Some of the visible hardware components on the 151X1230BR02SA02 Charger Board from GE Energy include its:

  • Type FL 52 block component (blue)
  • Large mounting backplane
  • Five backplane retention screws
  • FU1 and FU2 fuses

The various plugs in the assembly of the 151X1230BR02SA02 Charger Board are labeled similarly to the unit's fuses; PL1-PL3 to be exact.

Frequently Asked Questions about 151X1233DD01SA01R3

Does the 151X1230BR02SA02 Charger Board feature a block retention band?

No. While most similar units seem to feature a block component retention band over top, this 151X1230BR02SA02 Charger Board model is missing that. Call today if this is a necessary repair for your unit.

What type of product is the 151X1230BR02SA02 Charger Board?

The label "Type6" is available on the base circuit board of this unit.

Reviews For 151X1233DD01SA01R3

Internal Review
(5.0)

The 151X1230BR02SA02 Charger Board from GE outlet GE Energy sees its overall height at least doubled through the attachment of its mounting hardware. The 151X1230BR02SA02 Charger Board's circuitry is lifted from said hardware through standoffs. - AX Control Lead Technician

Repair Services For 151X1233DD01SA01R3

Type Lead Time Price Action
Repair Service 1-2 weeks Ask Get Quote

Our highly skilled technicians can repair your 151X1233DD01SA01R3. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
