The 151X1233DB01SA01R4 Power Converter Diode Assembly from GE Energy

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a 151X1233DB01SA01R4 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 151X1233DB01SA01R4
  • SKU: GBTC-59390
  • Manufacturer: GE Boards & Turbine Control
  • Series: 151X Boards and Modules

151X1233DB01SA01R4 Technical Specifications

Part Number 151X1233DB01SA01R4
Functional Description Power Converter Diode Assembly
Manufacturer GE Energy
CCB Revs AAA
PCB Revs AAA
Continuous Output Rating 10KW
Max Output Rating 25KW@100VDC
Plugs 1 External PL2 Plug

About the 151X1233DB01SA01R4

The 151X1233DB01SA01R4 Power Converter Diode Assembly here was originally designed by GE's subsidiary GE Energy manufacturer, with a number of critical hardware components available to its assembly including its:

  • DB+ and DB- Poles
  • Vented Metal Backplane
  • 12 Backplane Retention Screws and Holes
  • The PL2 Plug
  • The NEG and POS Screws

The NEG and POS-labeled screws in the assembly of this 151X1233DB01SA01R4 Power Converter Diode Assembly have been included on the same side of the product as the PL2 Plug, with the PL2 featuring in the middle of these two.

Frequently Asked Questions about 151X1233DB01SA01R4

What software package does the 151X1233DB01SA01R4 Power Converter Diode Assembly utilize?

This 151X1233DB01SA01R4 Assembly is compatible with the WP2L software package in specific.

How is the blue converter assembly on the 151X1233DB01SA01R4 installed?

The large, box-like converter assembly on the 151X1233DB01SA01R4 is itself secured through eight screws.

Reviews For 151X1233DB01SA01R4

Internal Review
(5.0)

The 151X1233DB01SA01R4 Power Converter Diode Assembly does not appear to offer numerous diodes on its surface, as they are more than likely stored within the chassis of its blue converter component. Heavy-duty vented chassis for protection and ventilation. - AX Control Lead Technician
