151X1233DB01SA01R Image One
3 year warranty
visa card logo american express logo master card logo bbb logo duns seal

About | Product Specifications | FAQs

151X1233DB01SA01R

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.86 (7)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.86 (7)
  • Click a star to rate this product
The 151X1233DB01SA01R Power Converter Control Board from GE Energy

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 151X1233DB01SA01R to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 151X1233DB01SA01R
  • SKU: GBTC-59372
  • Manufacturer: GE Boards & Turbine Control
  • Series: 151X Boards and Modules

151X1233DB01SA01R Technical Specifications

Part Number 151X1233DB01SA01R
Functional Description Power Converter Control Board
Continuous Output Rating 10KW
Max Output Rating 25KW@100VDC
PL2 Plug Type Female
Alternate Terminals DB+, DB-
Converter Assembly 109W6070P001
Conformity UL 508C

About the 151X1233DB01SA01R

The 151X1233DB01SA01R Power Converter Control Board from GE Energy was developed for that specific functional role through the addition of numerous hardware components to its assembly, including its:

  • 109W6070P001 Converter/Diode Assembly
  • S1-BUS and S2-BUS Components
  • Vented Metal Chassis
  • PL1 and PL2 Plugs
  • POS and NEG Terminals

It should be noted that this 151X1233DB01SA01R Power Converter Control Board's mentioned positive and negative terminals exist on teh 109W6070P001 Converter and Diode Assembly mentioned before, as too are its POS and NEG Terminals.

Frequently Asked Questions about 151X1233DB01SA01R

What is the software designated for the 151X1233DB01SA01R Power Converter Control Board from GE Energy?

This 151X1233DB01SA01R Control Board utilizes the WP2T software package.

What Control Board revision does the 151X1233DB01SA01R have?

Sticker labels designate this 151X1233DB01SA01R's Control Circuit Board revision table as ACB.

Reviews For 151X1233DB01SA01R

Internal Review
(5.0)

This 151X1233DB01SA01R Power Converter and Control Circuit Board possesses two noted revision packages; the ACB Control Circuit Board revision package and the AAA Power Circuit Board revision table. Buy or repair here now. - AX Control Lead Technician
