151X1225DB02MP01 Image One
3 year warranty
visa card logo american express logo master card logo bbb logo duns seal

About | Product Specifications | FAQs

151X1225DB02MP01

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
The 151X1225DB02MP01 Diode Bridge Module from General Electric

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 151X1225DB02MP01 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 151X1225DB02MP01
  • SKU: GBTC-59375
  • Manufacturer: GE Boards & Turbine Control
  • Series: 151X Boards and Modules

151X1225DB02MP01 Technical Specifications

Part Number 151X1225DB02MP01
Functional Description Diode Bridge Module
Revision Table Rev 1
Diodes Origin Italy
Connector Chassis-Ground
BUS Connectors S1-BUS and S2-BUS
Factory-Drilled Installation Holes 2 Holes

About the 151X1225DB02MP01

The 151X1225DB02MP01 Diode Bridge Module from General Electric has a number of hardware components in its assembly that all work towards introducing its functionality. Some of these would include its:

  • Thick metal vented backplane
  • S1-BUS and S2-BUS conenctors
  • Chassis-GND connection wire
  • 2 factory-drilled holes for installation

It does not appear that each of the 151X1225DB02MP01 Diode Bridge Module's two installation holes have been insulated like other contemporary models. The 151X1225DB02MP01 Diode Bridge Module's overall thickness is greatly increased by its backplane.

Frequently Asked Questions about 151X1225DB02MP01

Is the 151X1225DB02MP01 Diode Bridge Module fragile?

No and yes. While the 151X1225DB02MP01 Module is made out of sturdy metals, it does have numerous jutting metallic components that present bend risks.

Which rev does this 151X1225DB02MP01 embrace?

The 151X1225DB02MP01 Module is a revision 1 product.

Reviews For 151X1225DB02MP01

Internal Review
(5.0)

The 151X1225DB02MP01 Diode Bridge Module of course comes with a selection of diodes. The 151X1225DB02MP01 Module's base is well-ventilated given its thickness, and it is available on repair or replacement bases. - AX Control Lead Technician

Repair Services For 151X1225DB02MP01

Type Lead Time Price Action
Repair Service 1-2 weeks Ask Get Quote

Our highly skilled technicians can repair your 151X1225DB02MP01. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
