Product Description
The Eurotherm 620STD 0007 400 0010 UK ENW 0000 000 B0 000 000 is an AC drive developed for the 620 Vector series. A standard unit, this drive is best suited for systems that utilize analog setpoints as well as logic controllers. AC induction motors with appropriate encoders can be used with this drive, allowing for a high performance control of speed. Motor speeds for this drive measure at 0.75kW. From a source, this device can accept a rated nominal input voltage from 380 to 460 VDC. A UK device, frequencies for this drive measure at a European standard of 50Hz.
620STD/0007/400/0010/UK/ENW/0000/000/B0/000/000 features expanded I/O capabilities that allow users to easily interface with the drive. Five analog inputs are built into the drive, with four being user programmable. Two programmable analog outputs are also included with the drive. Digital inputs and outputs are also featured on the device. Three user programmable digital outputs rating 24 VDC are included, as well as 24VDC digital inputs controlling Run, Fast Stop, Coast Stop, Jog, Enable, Ramp Hold, and three presets. Braking options are highlighted features of this unit, with a factory installed brake power switch. A alphanumeric MMI (man machine interface) provides users with access to alarms, diagnostic information, and system parameters.
Following proper installation and storage parameters will ensure that the drive operates within its bounds. 620STD 0007 400 0010 UK ENW 0000 000 B0 000 000 is housed in a IP20 protected panel mounting enclosure. Ambient temperatures of the operating facility can safely range from 32℉ to 122℉. For a complete installation and wiring guide, refer to the series manual as well as the device datasheet. Eurotherm was the original technical support provider.
