What type of display does the P21-0C1-A4-1D3 use?

This P21-0C1-A4-1D3 Powerstation has a monochrome LCD display.

Does this P2 Powerstation have different shock ratings?

The P21-0C1-A4-1D3 has two different shock ratings; 10g peak, 11ms for operating and 30g peak, 11ms for non-operating.

DS200AAHA1	GE Turbine Control	Mark V

DS200AAHA1	GE Turbine Control	Mark V

Home CTC Parker Automation P2 PowerStations P21-0C1-A4-1D3

❮

❯

About | Product Specifications | FAQs

P21-0C1-A4-1D3

5.00 (2)
Click a star to rate this product

5.00 (2)
Click a star to rate this product

The P21-0C1-A4-1D3 Powerstation Module made for CTC Parker Automation's P2 Powerstations Series

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

1 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a P21-0C1-A4-1D3 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: P21-0C1-A4-1D3
SKU: CPA-59501

Manufacturer: CTC Parker Automation
Series: P2 PowerStations

Description
Repairs
Warranty
Manuals

P21-0C1-A4-1D3 Technical Specifications

Part Number	P21-0C1-A4-1D3
Series	P2 Powerstations
Manufacturer	CTC Parker
Input Voltage	20–36 VDC
Power Consumption	42W maximum
CPUs	PCA-6135 386SX, 40MHz • PCA-6145L 5x86, 133MHz
Display Gray Shades	16 shades
Weight	12.6 lbs
Fuse Type	3.15A, 250 VAC Littelfuse 216.315
Showering Arc	NEMA
Operating Temperature	IEC 68-2-1
Mechanical Shock	IEC 68-2-27

About the P21-0C1-A4-1D3

A number of critical hardware components are central to the functionality of this P21-0C1-A4-1D3 Powerstation Module. Some of these are its:

parallel port
two serial ports
Ethernet port
durable touchscreen
LED backlighting
PS/2 keyboard port

The Ethernet port present in this P21-0C1-A4-1D3 Powerstation's assembly can function either as an RS-232 or an RS-485.

P21-0C1-A4-1D3 Environmental Specs

A number of critical environmental specifications can be identified in the P21-0C1-A4-1D3's original literature attached above. Some of these include its:

32 to 122 degrees F operating temperature
10,000 hours LCD bulb life
25,000 hours color STN bulb life
25,000 hours color TFT bulb life
-200ft. to 10,000ft altitude

While it is a pretty sturdy module with a NEMA 4 faceplate, it is still recommended to keep this P21-0C1-A4-1D3 Powerstation away fromm common environmental hazards such as dust, dirt, or water.

Reviews For P21-0C1-A4-1D3

Internal Review

(5.0)

Motor oil, hydraulic fluid, and diesel fuel are just a few of the environmental hazards that this P21-0C1-A4-1D3 Powerstation is considered resistive to. The unit's COM1 and COM2 ports can both be used to connect a mouse as needed. This module's CRT port has been rendered a vestigial port and should be ignored during normal P21-0C1-A4-1D3 Powerstation use. - AX Control Lead Technician
